Installation
2 BC 9180-BT Cradle
Installation
To set up your BC9xx0-BT cradle you must:
1. Physically install the cradle.
2. Make all system connections.
3. Configure the BC9xx0-BT cradle.
Mounting the BC9xx0-BT Cradle
The cradle package contains the following items:
The cradle can be either mounted on a flat surface for desktop usage or
affixed vertically to a wall.
Mounting Brackets
The cradle comes with two different mounting brackets. The appropriate
bracket is used depending on whether the cradle will be mounted on a hori-
zontal or vertical surface. When shipped, the cradle has the Desktop Mount-
ing Bracket installed. For vertical installation, the Wall Mounting Bracket
must be attached instead.
Spare
(BC91x0-BT models only)
Green On = the spare battery is completely charged.
Orange Blinking = spare battery fault - replace spare battery.
Red/Green Alternatively Blinking = charging error - see PRG.
Off = no spare battery in the housing or battery not fully inserted.
Radio Yellow Blinking = radio activity.
Ethernet
(Ethernet models only)
Green Blinking = Ethernet activity.
• BC9xx0-BT Base Station (with Desktop
Mounting Bracket installed)
• 1 Metal Mounting plate
• BC9xx0-BT Quick Reference Guide
(this manual)
• 1 Wall Mounting Bracket
• 1 Ferrite Clamp (Ethernet models only)
