Datalogic BC9XX0-BT - Technical Features; Electrical and Bluetooth Features; Environmental and Mechanical Features

Technical Features
18 BC 9xx0-BT Cradle
Technical Features
* Having a switching regulator inside, the BC9XX0-BT draws the same power,
regardless of the supply voltage. i.e. as the input voltage increases the current
drawn decreases
Electrical Features
Supply Voltage
External Power
Host Power
10 - 30 VDC
5 VDC ±10%
Power Consumption
External Power
Host Power
max. 10 W (charging) *
max. 500 mA (charging)
Indicators Ext. Power/Data yellow LED
Host Power/Data yellow LED
Reader batt. state green/red LED
Spare batt. state green/red LED
Radio yellow LED
Ethernet green LED (Ethernet models only)
Time of Recharge
External Power
Host Power
max. 4 hours with 2150 mAh Li-Ion battery
max. 10 hours with 2150 mAh Li-Ion battery
Bluetooth Features
Protocol Bluetooth 2.0; Class 1; SPP (Serial Port Profile) or
HID (Human Interface Device) profile
Radio Frequency 2.40 to 2.48 GHz
Environmental Features
Working Temperature
Radio
Battery Charging
-20° to +50 C / -4 to +122 °F
0° to +40 °C / +32° to +104 °F
Storage Temperature -20° to +70 C / -4 to +158 °F
Humidity 90% non condensing
Protection Class IP40
Mechanical Features
Weight without metal plate about 390 g / 13.76 oz
Dimensions (without antenna) 235 x 108 x 80 mm
System Configuration BC9XX0-BT
Max number of devices per
base station
7
