CBX500 INSTALLATION MANUAL
14
TECHNICAL FEATURES
ELECTRICAL FEATURES
Supply Voltage 10 to 30 Vdc*
Consumption 0.5 – 0.3 A
Limited Current Consumption
CBX + reading device consumption
(see related manual)
2.5 A Max
Inputs 1 and 2
Non opto-isolated polarity insensitive
30 Vdc max; 12 mA max
Inputs 3 and 4
Non opto-isolated Pass through
Outputs 1 and 2
Opto-isolated polarity sensitive
30 Vdc max; 40 mA max continuous
130 mA max pulsed
Output 3
Non opto-isolated Pass through
USER INTERFACE
LED Indicators:
Power On/Polarity Error (blue/red), Trigger (yellow), IN2 (green)
OUT1 (yellow), OUT2 (green)
PHYSICAL FEATURES
Mechanical Dimensions 193 x 180 x 71 mm
(7.6 x 7.1 x 2.8 in.)
Weight about 780 g. (27.5 oz.)
ENVIRONMENTAL FEATURES
Operating Temperature
0° to 50 C (+32° to 122 °F)
Storage Temperature
-20° to 70 C (-4° to 158 °F)
Humidity max. 90% non condensing
Vibration Resistance 14 mm @ 2 to 10 Hz
EN 60068-2-6
2 hours on each axis
1.5 mm @ 13 to 55 Hz
2 g @ 70 to 200 Hz
Shock Resistance 30 g; 11 ms;
EN 60068-2-27 3 shocks on each axis
Protection Class
EN 60529
IP65 **
The features given are typical at a 25 C ambient temperature (if not otherwise indicated).
* for further details about minimum/maximum supply voltage refer to the manual of the
connected reading device, since the minimum supply voltage required may be >10.
** when compression connectors and reading device are correctly connected.
If Host Interface (Fieldbus) Modules are used, only correctly installed IP65 models
guarantee IP protection. Protection is not guaranteed when Standard Fieldbus Modules
are mounted.
