CBX800 INSTALLATION MANUAL
33
TECHNICAL FEATURES
ELECTRICAL FEATURES
Supply Voltage
10 to 30 Vdc*
Consumption
0.5 – 0.3 A
Limited Current Consumption
CBX + reading device consumption
(see related manual)
2.5 A Max
Inputs
Opto-isolated polarity insensitive
30 Vdc max; 12 mA max
Outputs
Opto-isolated polarity sensitive
30 Vdc max; 40 mA max continuous
130 mA max pulsed
COMMUNICATION INTERFACES
Host Interface
RS232/RS485 up to 115.2 Kbit/s
Auxiliary
RS232 up to 115.2 Kbit/s
Data Source
RS232/RS485 up to 115.2 Kbit/s
ID-NET™
RS485 Half Duplex up to 1 Mbaud
Communication Protocols
Datalogic Application Driver (DAD Driver)
USER INTERFACE
LED Indicators:
Power On/Polarity Error (blue/red), Trigger (yellow), IN2 (green)
OUT1 (yellow), OUT2 (green), Ready (green), Host (yellow), Source (green),ID-NET (yellow), OUT3 (green)
Configuration Modes
Genius™ utility program
Genius™ based Host Mode Programming
PHYSICAL FEATURES
Mechanical Dimensions
193 x 180 x 71 mm
(7.6 x 7.1 x 2.8 in.)
Weight
830 g. (29.28 oz.)
ENVIRONMENTAL FEATURES
Operating Temperature
0° to 50 C (+32° to 122 °F)
Storage Temperature
-20° to 70 C (-4° to 158 °F)
Humidity max.
90% non condensing
Vibration Resistance
14 mm @ 2 to 10 Hz; 1.5 mm @ 13 to 55 Hz;
EN 60068-2-6
2 g @ 70 to 200 Hz; 2 hours on each axis
Bump Resistance
30 g; 6 ms;
EN 60068-2-29
5000 shocks on each axis
Protection Class
EN 60529
IP65 **
The features given are typical at a 25 C ambient temperature (if not otherwise indicated).
* for further details about minimum/maximum supply voltage refer to the manual of the connected reading
device, since the minimum supply voltage required may be >10.
** when compression connectors and reading device are correctly connected.
If Host Interface (Fieldbus) Modules are used, only correctly installed IP65 models guarantee IP protection.
Protection is not guaranteed when Standard Fieldbus Modules are mounted.
