Configuration
20
BC9600 BASE STATIONS
CONFIGURATION
BC968X Ethernet Models
BC968x configuration can be performed using the Datalogic Aladdin software
configuration program or by reading configuration bar codes with the Power-
Scan™ PM9600 reader. For more details, refer to the Product Reference
Guide.
Non-Ethernet Models
The BC963X configuration can be performed in three ways: by using the Data-
logic Aladdin™ software configuration program, by sending configuration
strings from the Host PC via the RS232 or USB-COM interface or by reading
configuration bar codes with the PowerScan™ PM9600 reader.
Datalogic Aladdin™
Datalogic Aladdin™ (available for free download from the Datalogic website)
is a multi-platform utility program that provides a quick and user-friendly con-
figuration method via the RS232/USB-COM or Ethernet interface. It also
allows upgrading the software of the connected device (see the Datalogic
Aladdin™ Help On-Line for more details).
Serial Configuration
By connecting the BC963X to a PC through an RS232 or USB-COM interface
cable, it is possible to send configuration strings from the PC to the BC963X.
Configuration Bar Codes
Link the base station and the reader using the procedures described in the
Power- Scan™ PM9600 Quick Reference. Once the pairing is complete, you
can configure the base station by reading the configuration bar codes in the
PM9600 Quick Reference Guide or PowerScan 9600 Family Product Reference
Guide.
CAUTION: Do not place two base stations too close to each other as
shown in the figure below. Keep at least 5cm of distance between
them, in order to avoid possible interferences and malfunction of the
two wireless charging systems.
