Scan Modes
Quick Reference Guide
29
SCAN MODES
♦
Scan Mode = Trigger Single
Scan Mode = Trigger Hold Multiple
Scan Mode = Trigger Pulse Multiple
Scan Mode = Flashing
Scan Mode = Always On
Scan Mode = Stand Mode
$C
SN
RM
03
36
38
