DATAMAN S4 MANUAL
MOTOROLA S<$IFile Formats;Motorola>
Format 77
@LIST 2 = Carriage Return & Line Feed
S1 Data with 2 Byte Address
@LIST 1 = Position Character
@LIST 1 = 1-2
@LIST 2 = "S1"
@LIST 1 = 3-4
@LIST 2 = Record length = data bytes plus 3<R>
2 for address & 1 for checksum.
@LIST 1 = 5-8
@LIST 2 = 2 byte address as 4 HEX characters
Most Significant Byte
first.
@LIST 1 = 9-N
@LIST 2 = Data bytes in hexadecimal,<R>
each byte is two HEX characters.
@LIST 1 = N+1,2
@LIST 2 = Negation of checksum of bytes<R>
excluding "S1".<R>
Makes the line add up to "FF".
@LIST 1 = N+3,4
@LIST 2 = Carriage Return & Line Feed.
@LIST 2 =
S2 Data with 3 Byte Address
@LIST 1 = Position Character
@LIST 1 = 1-2
@LIST 2 = "S2"
@LIST 1 = 3-4
@LIST 2 = Record length .<R>
Number of data bytes plus 4<R>
(3 for address & 1 for checksum).
@LIST 1 = 5-10
@LIST 2 = 3 byte address as 6 HEX characters
Most Significant Byte
