DATAMAN S4 MANUAL
78MOTOROLA S<$IFile Formats;Motorola> Format
first.
@LIST 1 = 11-N
@LIST 2 = Data bytes in hexadecimal,<R>
each byte is two HEX characters.
@LIST 1 = N+1,2
@LIST 2 = Negation of checksum of bytes<R>
excluding "S2".<R>
Makes the line add up to "FF".
@LIST 1 = N+3,4
@LIST 2 = Carriage Return & Line Feed.
S8 End of File Record
@LIST 1 = Position Character
@LIST 1 = 1-2
@LIST 2 = "S8"
@LIST 1 = 3-4
@LIST 2 = "04" Record length.
@LIST 1 = 5-10
@LIST 2 = 3 byte start address usually "000000"
@LIST 1 = 11-12
@LIST 2 = Negation of checksum of bytes<R>
excluding "S8".<R>
Makes the line add up to "FF".
@LIST 1 = 13-14
@LIST 2 = Carriage Return & Line Feed.
S9 End of File Record
@LIST 1 = Position Character
@LIST 1 = 1-2
@LIST 2 = "S9"
@LIST 1 = 3-4
@LIST 2 = "03" Record length.
@LIST 1 = 5-10
@LIST 2 = 2 byte start address.
@LIST 1 = 11-12
@LIST 2 = Negation of checksum of bytes<R>
