DATAMAN S4 MANUAL
80Tektronix<$IFile Formats;TekHex> Format
@LIST 1 = 10-N
@LIST 2 = Data Bytes, each byte is two HEX
characters.
@LIST 1 = N+1,2
@LIST 2 = Two HEX characters show checksum
of HEX characters in Data Bytes
@LIST 1 = N +3,4
@LIST 2 = Carriage Return & Line Feed.
Tek End of File Record.
@LIST 1 = Position
@LIST 2 = Character
@LIST 1 = 1
@LIST 2 = "/" Slash character
@LIST 1 = 2-3
@LIST 2 = Four HEX characters show two byte
Start Address, most significant
byte first.
@LIST 1 = 6-7
@LIST 2 = "00" Byte count.
@LIST 1 = 9-10
@LIST 2 = Two HEX characters show checksum
of all previous HEX characters,
not including "/",
@LIST 1 = 11-12
@LIST 2 = Carriage Return & Line Feed.
Tek Extended Data Record.
@LIST 1 = Position
@LIST 2 = Character
@LIST 1 = 1
@LIST 2 = "%" Percentage character
@LIST 1 = 2-3
@LIST 2 = Two HEX characters expressing
character count in record,<R>
not including "%"
