DATAMAN S4 MANUAL
Tektronix<$IFile Formats;TekHex> Format81
@LIST 1 = 4
@LIST 2 = "6" for data record
@LIST 1 = 5-6
@LIST 2 = Checksum of all HEX characters not
including "%".
@LIST 1 = 7-N
@LIST 2 = Between 2 and 17 characters. The first
HEX character specifies
how many HEX characters follow showing Load
Address, most significant
byte first.
@LIST 1 = N-M
@LIST 2 = Data bytes, each byte is two HEX
characters.
@LIST 1 = M+1,2
@LIST 2 = Carriage Return & Line Feed.
LIST 1 = Position
@LIST 2 = Character
@LIST 1 = 1
@LIST 2 = "%" Percentage character
@LIST 1 = 2-3
@LIST 2 = Two HEX characters expressing
character count in record,<R>
not including "%".
@LIST 1 = 4
@LIST 2 = "8" for EOF record
@LIST 1 = 5-6
@LIST 2 = Two HEX characters expressing
checksum of all HEX characters
except "%".
@LIST 1 = 7-N
@LIST 2 = Between 2 and 17 HEX characters.
The first HEX character
specifies how many HEX characters follow
showing Start Address, most
significant byte first.
