Test an Diagnostics

Input Monitor – Display incoming GPIO binary signal states using the
DIAGNOSTICS  OPTIONS TESTING  TEST GPIO  MONITOR GPIO INPUT
selection.
SOP FEED PAUSE REPRT
1 1 1 1
 Note: Unused, non-connected inputs will have an indeterminate state, and may
assume a value of 1 or 0.
 Output Monitor – Display outgoing GPIO binary signal states using the
DIAGNOSTICS  OPTIONS TESTING  TEST GPIO  TEST GPIO OUTPUT
selection.
 Note: Unused, non-connected outputs will have an indeterminate state, and may
assume a value of 1 or 0.
 GPIO Report – Print the configuration and current signal state information using the
DIAGNOSTICS  OPTIONS TESTING  TEST GPIO  PRINT SIGNAL INFO
selection:
GPIO SIGNAL INFO
W ED 11:0 4A M 4JUL2 011
CARD ID#3
OUTPUT SIGNALS
END OF PRINT
PIN# 11 GPIO A
LOW P ULSE
CURRENT LEVEL 1
RIBBO N LOW
PIN# 9 G PIO A
ACTIVE LO W
CURRENT LEVEL 0
SERVI CE REQUIRED
PIN# 10 GPI O A
ACTIVE LO W
CURRENT LEVEL 1
ME DIA OU T
PIN# 12 GPI O A
ACTIVE LO W
CURRENT LEVEL 1
RIBBO N OUT
PIN# 13 GPI O A
ACTIVE LO W
CURRENT LEVEL 1
DATA READY
PIN# 14 GPI O A
ACTIVE LO W
CURRENT LEVEL 1
OPTIO N FAULT
PIN# 15 GPI O A
ACTIVE LO W
CURRENT LEVEL 1
INP UT SIGNALS
START OF PRINT
PIN# 3 GPIO A
A CTI VE HIG H
CURRENT LEVEL 1
FEED
PIN# 4 GPIO A
A CTI VE LOW
CURRENT LEVEL 1
TOGG LE PAUSE
PIN# 5 GPIO A
A CTI VE LOW
CURRENT LEVEL 1
REPRINT
PIN# 6 GPIO A
A CTI VE LOW
CURRENT LEVEL 1
EP RL SR MO RO DR OF
1 1 1 1 0 1 0
