Datamax I-class series User Manual

I-Class
Standard Features
I-Class Model
Feature
4206 4208 4212 4308 4406 4604
Direct Thermal Printing X X X X X X
Fan-Fold Media Handling X X X X X X
Flash Memory 1MB 1MB 2MB 2MB 2MB 2MB
Liquid Crystal Display X X X X X X
Media Tear Bar X X X X X X
Multi-Language Support X X X X X X
On-Demand and Batch Printing X X X X X X
Resolution (Dots Per Inch) 203 203 203 300 406 600
Rotating Media Hub X X X X X X
SDRAM 8MB 8MB 16MB 16MB 16MB 16MB
Scalable Font Engine X X X X X X
Serial & Parallel Ports X X X X X X
1.1.2 Optional Features (available except as noted)
The following optional features are offered for the printer:
Cutter, Light Duty
A rotary mechanism that cuts material with a maximum thickness of .005 inches (.127 mm)
in lengths as small as 1.25 inches (31.8 mm). An adjustable collection tray (200 label
capacity) can also be added.
Cutter, Standard Duty
A rotary mechanism that cuts material with a maximum thickness of .010 inches (.254 mm)
in lengths as small as 1.25 inches (31.8 mm). An adjustable collection tray (200 label
capacity) can also be added.
DMXNetII and DMXrfNetII
An internal wired or wireless Network Interface Controller for Ethernet
connectivity with
multiple operating system and protocol support, including trap functions.

Datamax I-class series Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Max Print Width	4.094" (104 mm)
Max Print Speed	6 ips (152 mm/s)
Connectivity	Serial, Parallel, USB, Ethernet
Media Sensor	Reflective sensor, transmissive sensor
Display	LCD
Media Types	Labels, tags, tickets
Label Length Range	0.25" (6.35 mm)
Operating Temperature	41°F to 104°F (5°C to 40°C)
Resolution	203 dpi (8 dots/mm)
