Datamax I-class series User Manual

I-Class
RFID
An integrated Radio Frequency Identification tag encoding and reading device with data
capture capabilities, available for immediate or future use:
• Factory Installed – complete, ready to use.
• Ready – factory installed antenna, requiring installation of additional hardware.
RS-422 Serial Interface (unavailable for I-4206 and I-4208 models)
Single-drop interface hardware for greater printer to host serial communication distances
(at up to 38,400 baud).
Thermal Transfer (specify ribbon configuration at time of order)
A device that allows the use of ribbon to produce exceptional image clarity (as compared to
most direct thermal media).
Twinax/Coax Interface
A slide-in circuit card that provides connectivity to AS/400 and System/3X Twinax host
systems or 3270-type host systems (cabling included).
USB Port
A slide-in circuit card that provides a Universal Serial Bus (Version 1.1) interface for
Windows
printing environments.
Option Installation
Experien
ce levels for option installations are detailed below. (Contact your dealer or
Datamax-O’Neil Technical Support for more information.)
Option Installations
Option Recommended Installer
Cutters / Trays – Light or Standard Duty Operator
DMXNetII or DMXrfNetII DMX Certified Technician
External Keyboard Operator
External Media Rewinder Operator
GPI/O Multi-Expansion Card DMX Certified Technician
Internal Rewinder Operator
Linear Scanner DMX Certified Technician

Datamax I-class series Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Max Print Width	4.094" (104 mm)
Max Print Speed	6 ips (152 mm/s)
Connectivity	Serial, Parallel, USB, Ethernet
Media Sensor	Reflective sensor, transmissive sensor
Display	LCD
Media Types	Labels, tags, tickets
Label Length Range	0.25" (6.35 mm)
Operating Temperature	41°F to 104°F (5°C to 40°C)
Resolution	203 dpi (8 dots/mm)
