Datapath VisionSDI2 User Manual

Chapter 3
Hardware Overview
• Dual Channel PCI express HD-SDI capture card
• Four lane PCIe bus with maximum data rate of 650MB/sec
• Support for all SD and HD video modes up to 1080p 60Hz
• Loop Through SDI BNC connections
• 64MB per channel, total 128MB on-board frame buer
• On board processor for real time mode and sync detection
• Audio output for each channel to an onboard SPDIF header (use with the Datapath AOM)
• High performance DMA to system memory or direct to graphics memory with scatter gather.
• High quality scaling (7x5 Polyphase Filter)
• Input indicator lights
• Long range, single co-ax cable support. (150 metres capturing 1080p, 300 metres capturing SD)
• 16 cropping windows per capture channel
• Wall Control support and SDK
Models
VisionSDI2 - A dual channel SDI video capture card.
3
