Datapath VisionSDI2 User Manual

Specication
Board Format PCI-e half size plug-in card, 110mm x 170mm
PCI-e bus master with scatter gather DMA providing maximum data
rate of 650MB/s
Connectors Four BNC connectors for SDI inputs (Green LED) and Loop through
outputs (Blue LED)
Maximum Capture Resolution 2 x 2048x1556
Frame Buer Memory 64MB per channel (total 128MB)
Audio Format Audio output for each channel in Digital SPDIF format. Channelled
out to RCA connectors using a Datapath Audio VIM.
Video Format Options SD-SDI, HD-SDI and 3G-SDI
Operating System Support Windows® XP, Windows® Vista, Windows® Server 2003, Windows®
Server 2008 and Windows® 7 (x86 and x64 Operating Systems)
Power Requirements Max current at +3.3V – 0.45A.
Max current at +12V – 0.85A.
Max power – 12W
Operating Temperature 0 to 35 deg C / 32 to 96 deg F
Storage Temperature -20 to 70 deg C / -4 to 158 deg F
Relative Humidity 5% to 90% non-condensing
Warranty 3 years
4

Datapath VisionSDI2 Specifications

General

Brand	Datapath
Model	VisionSDI2
Category	PCI Card
Language	English
