Page 3
For connecting Optical Expansion products please consult the User Guide located on
the documentation media.
STEP 2 CONNECT EXPANSION CHASSIS (OPTIONAL)
A VSN Expansion Chassis may have been purchased as part of a large video wall
system or ordered separately.
Connect the HLink-G3 card in the main system to the SLink-G3 card in the expansion
chassis using the ExCable-G3.
The ExCable-G3 is packaged and shipped with the VSN Expansion system.
