QUICK START GUIDE
Page 2
Each Datapath VSN wall controller is custom built to order therefore the
system.
types of input(s) and outputs and where they are located on the rear panel of the
system.
Any input cables supplied are clearly labeled and will indicate which of the system
input connectors they relate to.
Connect Keyboard and Mouse to convenient USB Ports.
USB Ports are located on both the front and rear panels of the system. If the
intention is to mount the VSN wall controller in a rack, it may be more convenient to
use the USB ports on the front for easy access.
• 4 x external USB 2.0 ports (2 front panel, 2 rear panel)
• 2 x external USB 3.0 ports (rear panel)
Rear Panel
Front Panel
STEP 1 KEYBOARD AND MOUSE
