Revision No. 005 August 2020
DataRemote 2020
SERVICE TECHNICIAN
INSTALLATION
Overview of the DataRemote DRI-9080 device.
SCOPE OF WORK.
The scope of work to be completed on-site includes the following:
The DataRemote DRI-9080 device is part of DataRemote's POTS (Plain Old Telephone
Service) IN A BOX product line. It is an ATA appliance that transmits over IP based wired networks
to directly replace wire-line POTS lines, including the capability for transmission of voice, FAX,
alarm, analog data, ring-down and emergency lines with full access to E-911.
▪ Locate existing devices (ie: Fire Panel(s), Call Boxes, Fax, Voice lines).
▪ Using a cable toner, locate demark / SNI for existing POTS lines currently serving devices.
▪ Unpack, assemble then test DataRemote DRI-9080 device in "Standalone" Mode with
power cable connected.
▪ Mount DataRemote DRI-9080 device and test FXS 1-8 phone jacks (if applicable) by calling
in/out using a telephone test set or simple line telephone and cell phone prior connecting any
device/appliance.
▪ Mount the biscuit (RJ-11 surface mount) jacks close to the DataRemote DRI-9080 device that
will connect with the device.
▪ Connect existing devices to newly installed RJ11 biscuit jacks.
▪ Ensure no "Foreign Voltage" is present by measuring the voltage at the tip and ring terminals
on the new biscuit jacks connected to the devices. Voltage should read: “zero” volts DC
(direct current)
IMPORTANT! IF foreign voltage is present, locate and disable it. IF
no foreign voltage is present, proceed to next step
▪ Connect the DataRemote DRI-9080 device FXS 1-8 jacks (if applicable) to existing devices.
▪ If Call Box or Voice line, test by making inbound/outbound calls.
▪ If Call Box also test 'Gate/Door Entry" tone (DTMF / 'Press 9") and programming calls inbound to
the device. Request client or call vendor technical support to facilitate programming test calls as
needed.
▪ If Fire Alarm Panel included in install, test that Fire Alarm Panels primary & secondary lines
accordingly, by calling out through the DataRemote DRI-9080 device. If RJ-31 style jack is used,
verify that tip/ring connections are on pins 4 & 5 of jack.
▪ IF FAX, test by sending/receiving FAX using customer equipment (Note: changes may have to be
made to customer equipment ex: ECM on/off)
▪ Call in to your remote support team to sign off on install verification
Page 9
