BWS-T2 Series Instructions manual
18
VOLTAGE
SUPPLY
24 V + 10 %
-
+
-
EL. CONTROL CABINET
302928272617 18 19 20 21 23 24 252216
EMITTER
RECEIVER
max. 220 VAC
FUSE
TEST1 TEST2
151234567891011 1312 14
START
L1
N
S
H
I
E
L
D
O
T
1
U
O
T
2
U
User tool
User tool
SB-BW S-T2
+ - - +
Figure 11 - One Emitter/Receiver pair
If only one User Tool is used, the output contacts can be tied together.
NOTE
Be sure that L1 is switched by the 2 outpu
t
contacts and not N.
