Datavideo DAC-100 - MEET THE DAC-100; Input Side Overview; Output Side Overview

Audio Bit Rate Selector
Input Selector
Source Indicator
Audio
Bit Rate Indicator
S-Video
Input
Composite Video Input
Left Audio Input
Right Audio Input
S-Video Output
Composite Video Output
Left Audio Output
Right Audio Output
INPUT SIDE
OUTPUT SIDE
Dip Switches
(Behind the Plastic Cover)
AC Adapter Connector
Power Switch
MEET THE DAC-100
FireWire
Input/Output
FireWire
Input/Output
2
