6
VideoColorCorrection Adjustment
Pushontheknobtoselecttheparameter(Color,Contrast,Brightness
orTint(NTSConly))thatyouwanttoadjust;repeatedpusheswill
togglethroughtheoptions.
Turnthebuttonclockwisetoincreasethevalueoranticlockwiseto
decreasethevalue,youwillseethesettingsdisplayedontheLED
displayabove.
Note:
Pressontheknobandholdforthreesecondstoresetalladjustments
backtodefault(unity)
AudioLevelAdjustments
TheAudioLevelAdjustmentsallowyoutoindependentlyadjustthe
audiolevelofboththeleftandrightchannels.TheAudioInputLevel
LEDsshowtheaudioinputlevel,thelevelshouldbeadjustedsothat
theLEDsupto0dBareilluminatedand+4/+8onlylightupwhenloud
noisesoccur.
AudioInputLevelLEDs
TheAudioInputLevelLEDsshowtheaudioinputlevelsfromthe
incomingsource
