Datavideo DAC-15 - Rear Panel ­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­­7

7
RearPanel
DVIN/OUTPorts
2xDVI/OPortsforconnectingtoDVCamcordersDecks/NLEsystems
withIEEE1394(iLink,FireWire)
DipSwitches/Mode Select
TheDAC15canbesettovariousmodesusingtheDipSwitches.
Note:ReboottheDAC15ifyouhavechangedaDIPSwitch)
DipSwitch 1:OFF=NTSC,ON=PALoutput
2:OFF=0IRE, ON=7.5IREinput/output
3:ON=UnlockedAudio(Default)OFF=LockedAudio
4ON5ON MACOS
4ON5OFF WindowsXP/ME(Default)
4OFF5ON SMARTDV*(SeeNote
Below)
4and5
4OFF5OFF CameraMode
6:FactoryDefaultOFF–DONOTCHANGE
CompositeandSVideo(Y/C)IN/OUT+unbalan cedAudioIN/OUT
CompositeandSVideoinputsandOutputsandstereoaudioinputsand
outputsforconnectinganalogvideodevices/monitorstotheDAC15.
BothCompositeandSVideocanbeconnectedwithoutanyconflict.
ComponentVideoInput
ComponentYUVVideoInput,commonlyusedwithBetacam,DVCPro,
someDVDPlayers
