Datavideo DAC-9P - Specification

9
Specification
Input Interface • 1x HDMI input
Outputs Interface
• 2x 3G/HD/SD-SDI output
Video Support Format
(HDMI Input)
• 720x480 Interlace
• 720x576 Interlace
• 1280x720 / 50Hz Progressive
• 1280x720 / 59.94Hz Progressive
• 1280x720 / 60Hz Progressive
• 1920x1080 / 50Hz Interlace
• 1920x1080 / 59.94Hz Interlace
• 1920x1080 / 60Hz Interlace
• 1920x1080 / 50Hz Progressive
• 1920x1080 / 59.94Hz Progressive
• 1920x1080 / 60Hz Progressive
3G SDI
Signal
SMPTE 292 standard complied with
• Output return loss : More than 4.5 dB (3GHz)
• Output level : 0.8 Vpp ± 10%
• Rise time : Less than 130 ps
• Fall time : Less than 130 ps
• Difference between rise time and fall time within 50 ps
• Alignment jitter : Less than 0.3 UI
• Timing jitter : Less than 2.0 UI
• Rise over shot：10%
• Fall over shot：10%
• Equalizer use 5C-FB cable support 100 meters
SD SDI signal
SMPTE 292M standard complied with
• Output return loss : More than 15 dB (5MHz to 750MHz)
More than 10 dB (750MHz to 1.5 GHz)
• Output level : 0.8 Vpp ± 10%
• Transition time : 0.4 ~ 1.5ns
• Difference between rise time and fall time within 100 ps
• Alignment jitter : Less than 0.2 UI
• Timing jitter : Less than 0.2 UI
• Eye aperture ratio : More than 90%
• DC offset : 0 ± 0.5V
• Equalizer use 5C-FB cable support 200 meters
Operating Temperature
• 0°C to 40°C (32°F to 102°F)
Humidity
• 10% to 90% (non condensing)
Dimension & Weight
• 145mm (W) x 85mm (D) x 30mm (H) / lbs/ 0.33Kgs
Power
• DC 12V / 500mA (5W)
