User’s Manual1 DATECS LP-1000
12 13
DAILY MAINTENANCE
At the time of maintenance, be sure to turn off the power switch of the printer
and unplug it from the socket.
Use a dry soft cloth to wipe off stains and dust from the surfaces of the main
body case. For severe soiling, dip the cloth in water and wring it, for wiping
off the soil. Never use organic solvents, such as alcohol, thinner, trichlene,
benzene, ketone, or chemical dusters.
If the equipment is contaminated with paper powder, use a soft brush
to clean it. Be careful not to damage the printing head.
Cleaning the Printing Head
1. Moisten gauze slightly with alcohol, and clean the heating surface of the
printing head with it.
2. Reattach the platen roller unit.
The printing head and motor are very hot. Be careful not to touch
them immediately after printing. Do not touch the heating surface of
the head with a bare hand or metal. When detaching or reattaching
the platen roller unit, be sure to raise up the printing head, other-
wise, they could be damaged. Handle the detached platen roller unit
carefully so as not to damage it.
!
1. Outline
This manual describes the disassembly, reassembly, and mainte-
nance procedures of the Label printer LP-1000. Also it includes block
scheme,electrical diagram of the PCB, the PCB, technical & electrical
specifications of the printer.
1.1 Features
The LP-1000 is designed for printing on small size labels or graphical
images to termo-sensitive paper.
Label printer
Compact design
Low-noise printing
Use of 80 mm- or 58 mm Label paper roll.
Built-in Serial RS232 Interface
Built-in input buffer
Bar code printing
High-speed printing at 50 to 150 mm/s max.
Built-in Interface for External Display
Power supply - AC adaptor
Built-in Drawer Kick-out interface
!
CAUTION
