EN Dateq BCS70 Manual BCS70 connector board 20
BCS70 PGM-L/R/M / AUD-L/R/M / AUX-L/R/M (XLR 3p male)
Pin Function Type
1 Audio GND A-GND
2 Audio + Out
3 Audio - Out
BCS70 CLOCK ANTENNA (TRS stereo jack)
Pin Function Type
Tip Antenna + In
Ring Antenna - In
Sleeve Frame GND FRAME
BCS70 TOP CONSOLE (Sub-D 25p female)
Pin Function Type
1 Extra Meter 1 Left Out
14 Extra Meter 1 GND A-GND
2 Extra Meter 1 Right Out
15 Extra Meter 2 Left Out
3 Extra Meter 2 GND A-GND
16 Extra Meter 2 Right Out
4 Extra Meter 3 Left Out
17 Extra Meter 3 GND A-GND
5 Extra Meter 3 Right Out
18 -15V Power Supply POWER
6 Extra Meter 4 Left (2nd function: Timer Control 1) Out
19 Extra Meter 4 GND A-GND
7 Extra Meter 4 Right (2nd function: Timer Control 2) Out
20 +12V Power Supply POWER
8 +12V Power Supply POWER
21 Main Meter Left Out
9 Main Meter GND A-GND
22 Main Meter Right Out
10 GND Power Supply D-GND
23 GND Power Supply D-GND
11 DCF Antenna Signal + Out
24 DCF Antenna Signal - Out
12 BCSBus Data
25 Digital Ground POWER
13 BCSBus Data
