Datex-Ohmeda Tec 5 - Fig.17 Tec 5 Vaporizer Gas Flow

Page 20 Tec 5 Vaporizer
August 1999 O & M Manual Part No. 1105-0100-000
With the vaporizer correctly fitted and turned OFF the vaporizer is isolated from the gas flow.
With the vaporizer correctly fitted and turned ON, the gas flow through the vaporizing chamber circuit is
via
1
through to
bl
and the gas flow through the by-pass circuit is via a through to e .
015A T5 OM
Fig. 17 Tec 5 Vaporizer Gas Flow
ROTARY
VALVE
ENRICHED
FRESH
GAS OUT
d
10
COMBINED
FRESH GAS
AND ENRICHED
GAS OUT
11
e
c
THERMOSTAT
VAPORIZING
CHAMBER
b
8
WICK
ASSEMBLY
6
5
7
9
4
a
1
3
2
ON
VAPOUR
CONTROL
CHANNEL
FRESH
GAS OUT
FRESH GAS
BY-PASS
IPPV
COMPENSATING
ASSEMBLY
AA.13.063
