16 Oscillators
Dave Smith Instruments
Oscillator 1 can be hard-synced to Oscillator 2 for complex, harmoni-
cally-rich sounds when modulated.
Oscillator 2 features a
fine knob for detuning and thickening sounds,
a
low freq switch that allows it to function as an LFO for modulation
purposes, and a keyboard switch that disables keyboard control over its
pitch (useful when used as an LFO, or for drones and other effects).
Oscillator Parameters
Frequency: Sets the base oscillator frequency over a 9-octave range from
16 Hz to 8KHz (when used with the Transpose buttons). Adjustment is in
semitones.
The global Master Tune settings affect the pitch of all oscillators. See “Globals -
Top Row” on page 11 for more information.
Fine: Fine tune control with a range of a quartertone up or down. The 12
o’clock position is centered. Steps are in cents (50 cents = 1/2 semitone).
Shape: Triangle, Sawtooth, Pulse—Used to select the waveshape
generated by the oscillator. Waveshapes are continuously variable and
smoothly transition from one shape to the next as you turn the shape
knob. This provides a variety of “in-between” waveshapes.
Pulse Width: Changes the width of the pulse wave from a square wave
when the
pulse width knob is at center position, to a very narrow pulse
wave when the pulse width knob is full left or right.
Applying pulse width modulation using poly mod or the low frequency oscillator
is a great way to add movement and thickness to a sound, especially when creating
pad or string-like sounds.
