20
8.3 Spare parts listing – single impeller
Notes: A. 2 required for 4 way outlet, 1 only for three way outlet.
B. Viton seal kit contains the elastomers from items 1, 4, 10, 11, 12, 14, 17 & 22.
C. The STD seal kit consists of items 6, 7, 9, 10, 11, 12.
D. Tapped priming plug used when installing a pressure gauge.
ITEM NOTES DESCRIPTION
QTY
REQ’D PART NO.
1 Priming/Drain Plug & O-ring Assy 2 32162
2 Kit - Bolt & nut (pk 6) 1 32163
3
Casing Assy - Yellow 2" BSPT - HQ models & models tted with GX270,
GX390 & L100N engines
1 14395-2SPY
3 Casing - Yellow 1.5" BSPT All other models not specied 1 13040SPY
3
Casing Assy - Yellow 2" NPT - US HQ models & US models tted with GX270,
GX390 & L100N engines
1 14395-1P
3 Casing - Yellow 1.5" NPT All other US models not specied 1 14395-1
4 Flap Valve Assy 1 13081-3SP
4 Flap Valve Assy - Viton 1 32182SP
5 Diffuser coverplate - models tted with GX270, GX390, L100N engines 1 13454
5 Diffuser coverplate All other models not specied 1 13158SP
6 Neckring - models tted with GX270, GX390, L100N engines 1 13452M
6 Neckring All other models not specied 1 13044
7 Screw - Impeller (pk 4) 1 13367*4
8 Impeller Assy - 1 stage 3/4" - models tted with L70N engines 1 13447
8 Impeller Assy - 1 stage 1" - models tted with GX270, GX390 engines 1 13416
8 Impeller Assy - 1 stage 35mm 5110YE only 1 13416-1
8 Impeller Assy - 1 stage 5/8" All other models not specied 1 13446
8a Impeller front - 1st stage Not suited to models tted with GX270, GX390, L100N engines 1 13043SP
8b
Impeller back 1 stage 5/8" incl screw - models tted with GP160, GX160, GX200,
L48N and L70N engines
1 13394SP
8b Impeller back 1 stage 3/4" incl screw -models with L70N engine only 1 13394-1SP
9 Neckring balance 1 13366
10 Kit - Bolt, Washer, Oring (pk4) 1 31327*4
11 Seal - Mechanical 35mm (Type 2100) - models tted with L70N engine only 1 48816
11 Seal - Mechanical 3/4" - models tted L100N engine only 1 48803SP
11 Seal - Mechanical 33mm (Type 2100) - models tted with GX270, GX390 engines only 1 48779
11 Seal - Mechanical 5/8" (Type 6) All other models not specied 1 48801SP
12 O-ring - Casing 1 43063
13 Casing - Rear - 35mm - models tted with L100N engines 1 13039-3MSPY
13 Casing - Rear 3/4" yellow - models tted with L70N engines only 1 13039-2MSPY
13 Casing - Rear yellow - models tted with GX270 and GX390 engines only 1 13039-1MSPY
13 Casing - Rear yellow 5/8" All other models not specied 1 13039MSPY
14 Gasket - Discharge 3 way 1 13539
14 Gasket - Discharge 4 way 1 13099
15 Outlet 3 way 2" BSPT - models tted with GX270, GX390, L100N engines 1 13497SPY
15
Outlet 3 way 1.5" BSPT - models tted with GX160 and GX200 engines with 3-way discharge
1 13497-1SPY
15
4 way discharge - yellow BSPT - other models tted with GX160 and
GX200 engines & bareshaft models
1 13077SPY
15 4 way discharge (no handle) - yellow BSPT - models tted with L70N engines only 1 13077-2SPY
15
Outlet 3 way 1.5" NPT - models tted with GX160 and GX200 engines with
3-way discharge
1 13498
16 Screw - Outlet (pk3) 4 way discharge 1 9615-10*3
16 & 28 E Discharge Screw Kit (Tapped Casings) 1 33004
17 A Cap assy - Blank 1.5" BSP (includes 13490 gasket) 2 32164
18 A Gasket - 1 1/2" cap 2 13490
19 Cap assy - Blank 1" BSP (includes 13489 gasket) 2 32165
20 Gasket - 1" cap 2 13489
21 Gasket - 2" cap 1 13540
22 Cap - 2" BSP 1 13541
23 Bracket - Front Case yellow - models tted with GX270, GX390 engines 1 13425
28 Screw - Handle (pk3) 3 way discharge 1 32257
29 PCB Remote Start FF 5190HRS-0 1 402944SP
29 PCB Remote Start FF 5190HRS-1, 5190HRS2 1 403283SP
30 Spring - Control Box Remote Start FF 1 15724
B Viton seal kit - 5 series All other models - Not illustrated 1 32184
B Viton seal kit - 5/8" 1 stage 3 way H3 & HQ models only - Not illust. 1 32244
B Viton seal kit - 3/4" 1 st 4 way outlet 5170Y/YE only - Not illustrated 1 32236
B Viton seal kit - 35mm 1 st 3 way - models tted with L100N engines - Not illustrated 1 32247
B Viton seal kit - 33mm 1st 3 way - models tted with GX270, GX390 engines - Not illust. 1 32212
C Seal Kit - models tted with L100N engines (1 stage) 1 32330
C Seal Kit - models tted with GX160 and GX200 engines (1 stage) 1 32332
C Seal Kit - models tted with L70N engines (1 stage) 1 32329
C Seal Kit - models tted with GX270 and GX390 engines (1 stage) 5 Series 1 32331
Buffer kit 1 32373
Disc - Location - models tted with GX270 and GX390 engines - Not illust. 1 12625-1
D Plug drilled & tapped (5 series) Not illustrated 1 13553SP
O-ring - Priming plug pk 6 1 42999*6
