David White DWT-10 User Manual

4
1.2.1 Display
DISPLAY FUNCTION
V
Vertical angle symbol
will be shown in place of the vertical reading until the telescope
has been turned past the zero point of the horizontal axis. This
sets the zero point.
(See section 1.2.3, preference set up)
HR Horizontal angle counterclockwise symbol
H L
Horizontal angle clockwise symbol
Battery strength symbol
(See section 4, power)
Angular measurements are in gons
(See section 1.2.3, preference set up)
G
%
Vertical reading shown as percent of grade
(see section 1.2.3, preference set up)
1.2 Part Functions
R L V %
HOLD OSET
V
-8.8.8.8.8.8.8.
H RL
8.8.8.8.8.8.8.
G
R L V %
HOLD OSET
V
HR
0.0.0.0.0.0.0.
