Specifications
Meridian L6-20N Level
Meridian LT6-900N Level-Transit
Optimum sighting range: Recommended job range up to 200 feet.
Accuracy range:
Recommended for jobs requiring accuracy within
1/4"
at 75 feet.
TELESCOPE
Power
22X
Length 10.5" (26.5cm)
Minimum Focus 4 ft. (1.2m)
Aperture .75" (19mm)
Field of View 2' @ 100' (.6m @ 30m)
No. of Lenses 6
HORIZONTAL CIRCLE
Graduation Diameter 3.62" (92mm)
Graduations Each 1°
Numbers Each 10°, 0-90-0°
Vernier Double direct to 15 min.
VERTICAL ARC (LT6-900N only)
Graduations Each 1°
Numbers Each 10°, 45-0-45°
CENTER Planar bearing
LEVEL VIAL 10 min. per 2mm
WEIGHT L6-20N LT6-900N
Instrument only 3.25 lbs. (1.5kg) 4.5 lbs. (2.0kg)
Instrument, case,
3 oz. plumb bob 6 lbs. 6 oz. (3kg) 7 lbs. 10 oz. (4kg)
CASE Double-walled polyethylene
TRIPOD 5/8 x 11 JIS
