Davis Instruments Vantage VUE Quick Reference Guide

19
To set an alarm:
1. Press 2
ND
then ALARM to enter Alarm Mode. The alarm bell icon will
appear on the screen. In each field, you will either see the alarm setting
or, if no alarm has been set, a series of dashes.
2. Press a weather variable key, or use +, – , <, or > to move between
weather variables. Except for the time alarm, the arrow icon displays next
to the variable you have selected.
3. Press HI/LOW to switch between high and low alarms. (Note: Not all
alarms are available for all weather variables. See Vantage Vue Console
Manual for details.)
4. Press 2
ND
then SET to enter or change an alarm setting. Use + or – to
change the digit within a field. Use < or > to move to the next field. Press
DONE to accept the alarm setting. Repeat steps 2–4 to set another
alarm, or press DONE again to exit the alarm screen.
Set Alarms

Davis Instruments Vantage VUE Specifications

General

Console Display Type	LCD
Wind Direction Range	0 to 360°
Wind Direction Accuracy	±3°
Temperature Accuracy	±1°F (±0.5°C)
Humidity Accuracy	±3%
Solar Radiation Range	0 to 1800 W/m²
Solar Radiation Accuracy	±5%
UV Index Range	0 to 16
Wireless Transmission Range	1000 feet (300 meters)
Update Interval	2.5 seconds
Temperature Range	-40°F to +150°F (-40°C to +65°C)
Humidity Range	0 to 100% RH
Rain Collector Resolution	0.01 inches (0.2 mm)
Wind Direction Resolution	1°
Power Source (Integrated Sensor Suite)	Solar panel with battery backup
Power Source (Console)	AC adapter or 3 C batteries
Wind Speed Accuracy	±2 mph (±3 kph) or ±5%, whichever is greater
Rainfall Accuracy	±4%
Operating Temperature	-40°F to +140°F (-40°C to +60°C)
Wind Speed Range	0 to 150 mph (0 to 241 km/h, 0 to 67 m/s)
