Davis Instruments Vantage VUE Quick Reference Guide

4
Setup Mode
To enter Setup Mode:
1. Press and release 2ND and then press SETUP.
2. Press DONE to advance or BAR to step back through setup screens:
• TIME AND DATE — Press < and > to move between segments. Press
+ and - to change the value of the flashing segment. Press 2nd and
UNITS to change from 12-hour to 24-hour clock.
• TIME ZONE — Press + and - to cycle through time zones. Press 2ND
then + and - to set UTC offset.
• DAYLIGHT SAVING SETTINGS — Press + or - to choose MANUAL or
AUTO.
• DAYLIGHT SAVING STATUS — If daylight savings setting = AUTO,
displays current status. If daylight savings setting = MAN, press
+ or - to turn DST on or off.
• RECEIVING FROM — Displays the transmitter IDs the console is
currently receiving. (It may take several minutes to display all IDs.)

Davis Instruments Vantage VUE Specifications

General

Console Display Type	LCD
Wind Direction Range	0 to 360°
Wind Direction Accuracy	±3°
Temperature Accuracy	±1°F (±0.5°C)
Humidity Accuracy	±3%
Solar Radiation Range	0 to 1800 W/m²
Solar Radiation Accuracy	±5%
UV Index Range	0 to 16
Wireless Transmission Range	1000 feet (300 meters)
Update Interval	2.5 seconds
Temperature Range	-40°F to +150°F (-40°C to +65°C)
Humidity Range	0 to 100% RH
Rain Collector Resolution	0.01 inches (0.2 mm)
Wind Direction Resolution	1°
Power Source (Integrated Sensor Suite)	Solar panel with battery backup
Power Source (Console)	AC adapter or 3 C batteries
Wind Speed Accuracy	±2 mph (±3 kph) or ±5%, whichever is greater
Rainfall Accuracy	±4%
Operating Temperature	-40°F to +140°F (-40°C to +60°C)
Wind Speed Range	0 to 150 mph (0 to 241 km/h, 0 to 67 m/s)
