Davis Instruments Vantage VUE Quick Reference Guide

5
Setup Mode
• ACTIVE TRANSMITTERS — Press < or > to select ID, use + or - to set
to ON (to receive from that station) or OFF. Press GRAPH to change
station type: ISS, VP2, WIND.
• RETRANSMIT — Press + or - to set the retransmit function ON or
OFF.
• LATITUDE & LONGITUDE — Press < or > to move between
segments. Press + or - to change the value of the flashing segment.
Press 2ND and UNITS to toggle between NORTH and SOUTH (for
latitude) or EAST and WEST (for longitude).
• ELEVATION — Press < or > to move between segments. Press + or -
to change the value of the flashing segment. Press 2ND and UNITS to
toggle between FEET and METERS.
• BAROMETRIC REDUCTION — Press + or - to change barometric
setting types: NOAA (default), ALT SETTING (Altimeter), or NONE.

Davis Instruments Vantage VUE Specifications

General

Console Display Type	LCD
Wind Direction Range	0 to 360°
Wind Direction Accuracy	±3°
Temperature Accuracy	±1°F (±0.5°C)
Humidity Accuracy	±3%
Solar Radiation Range	0 to 1800 W/m²
Solar Radiation Accuracy	±5%
UV Index Range	0 to 16
Wireless Transmission Range	1000 feet (300 meters)
Update Interval	2.5 seconds
Temperature Range	-40°F to +150°F (-40°C to +65°C)
Humidity Range	0 to 100% RH
Rain Collector Resolution	0.01 inches (0.2 mm)
Wind Direction Resolution	1°
Power Source (Integrated Sensor Suite)	Solar panel with battery backup
Power Source (Console)	AC adapter or 3 C batteries
Wind Speed Accuracy	±2 mph (±3 kph) or ±5%, whichever is greater
Rainfall Accuracy	±4%
Operating Temperature	-40°F to +140°F (-40°C to +60°C)
Wind Speed Range	0 to 150 mph (0 to 241 km/h, 0 to 67 m/s)
