Davis Instruments Vantage VUE Quick Reference Guide

22
To clear daily, monthly or yearly HIGH/LOW data:
1. Press HI/LOW.
2. Select the variable you wish to clear.
3. Press 2ND then CLEAR, holding CLEAR down until the digits stop
flashing and zeroes or dashes appear in the field.
To clear a single alarm setting:
1. Press 2ND then ALARM.
2. Select the alarm reading you wish to clear.
3. Press 2ND then CLEAR, holding CLEAR down until the digits stop
flashing and dashes appear in the fields.
4. Press DONE to return to the current weather screen.
To Clear All:
1. To clear all highs and lows and all alarms, press WIND, then 2ND, then
CLEAR, holding CLEAR down for the entire 6-second countdown until
you see CLEARING NOW in the Weather Center.
Clear

Davis Instruments Vantage VUE Specifications

General

Console Display Type	LCD
Wind Direction Range	0 to 360°
Wind Direction Accuracy	±3°
Temperature Accuracy	±1°F (±0.5°C)
Humidity Accuracy	±3%
Solar Radiation Range	0 to 1800 W/m²
Solar Radiation Accuracy	±5%
UV Index Range	0 to 16
Wireless Transmission Range	1000 feet (300 meters)
Update Interval	2.5 seconds
Temperature Range	-40°F to +150°F (-40°C to +65°C)
Humidity Range	0 to 100% RH
Rain Collector Resolution	0.01 inches (0.2 mm)
Wind Direction Resolution	1°
Power Source (Integrated Sensor Suite)	Solar panel with battery backup
Power Source (Console)	AC adapter or 3 C batteries
Wind Speed Accuracy	±2 mph (±3 kph) or ±5%, whichever is greater
Rainfall Accuracy	±4%
Operating Temperature	-40°F to +140°F (-40°C to +60°C)
Wind Speed Range	0 to 150 mph (0 to 241 km/h, 0 to 67 m/s)
