Repeater Board Contents
The board contained within the repeater enclosure has the following components:
Transmitter
DIP Switches
Repeater
DIP Switches
Repeater
Test Switch
TX
LED
Status
LED
1
2
3
4
56
78
Solar Power Input AC Adapter Socket
Battery Socket
First In Chain
Jumper
