18
To change to another ID, use a ballpoint pen or paper clip to toggle DIP switches
#1, 2, and 3. The settings for Transmitter IDs 1 - 8 are shown in the table below.
Set the Vantage Pro2 console to the same ID as the transmitters, as described in
the Vantage Pro2 Console User Manual.
Using Multiple Transmitting Stations
This table shows the maximum number of each type of station that can be used with
a single Vantage Pro2 console.
The console can receive signals from a total of up
to eight transmitters (stations).
*Replaces the sensor suite anemometer.
**Two are allowable only if one stations has only leaf wetness and one has only soil moisture sensors.
For example, a network can either have both a Leaf Wetness/Temperature station and a Soil Moisture/
Temperature station, or it can have one combined Leaf Wetness and Soil Moisture/Temperature station.
ID CODE SWITCH 1SWITCH 2SWITCH 3
#1 (default) off off off
#2 off off ON
#3 off ON off
#4 off ON ON
#5 ON off off
#6 ON off ON
#7 ON ON off
#8 ON ON ON
Station Type Maximum Number
Integrated Sensor Suite (sensor suite) 1
Anemometer Transmitter Kit* 1*
Leaf & Soil Moisture/Temperature Station 2**
Temperature Station 8
Temperature/Humidity Station 8
