Optional: Adding an External Temperature Probe (Wireless Envoy Only)
6
1. Locate the power adapter jack on the end of the Envoy case. It’s next to the
data logger output cable.
2. Insert the power adapter plug into the power jack.
Optional: Connecting a Cabled Envoy to the Integrated Sen-
sor Suite (ISS)
Refer to the figure shown above “Connecting AC Power”.
1. Insert the modular plug into the ISS jack on the Envoy case.
Note: You won’t be able to test the connection between the Envoy and the ISS until you
have finished installing the WeatherLink software.
Optional: Adding an External Temperature Probe
(Wireless Envoy Only)
Your wireless Weather Envoy has a built-in temperature-humidity sensor as
well as the barometer. The temperature and humidity are reported as “Inside
Temperature” and “Inside Humidity.”
In some instances, such as when your Envoy is mounted outside in a shelter,
the temperature inside the shelter is of little interest. You may replace the
built-in temperature-humidity sensor with an external temperature probe, with
a 25’ (7.6 m) cable, which can be used to measure the temperature of air,
water, or soil. The External Temperature Probe with RJ connector comes in
RJ Jack
RJ Connector
from Cabled ISS or
Optional External
Temperature
Probe
Insert Power
Adaper
Plug and rotate
to fit

DAVIS Vantage Pro2 Specifications

General

Update Interval	2.5 seconds
Temperature Accuracy	±1°F (±0.5°C)
Barometric Pressure Range	16.00 to 32.50 inHg (540 to 1100 hPa)
Rain Collector Type	Tipping bucket
Wind Speed Range	0 to 200 mph (0 to 322 km/h)
Wind Speed Accuracy	±2 mph (±3 km/h) or ±5%, whichever is greater
Wind Direction Resolution	1°
Wind Direction Accuracy	±3°
Solar Radiation Range	0 to 1800 W/m²
Solar Radiation Sensor Accuracy	±5%
UV Index Range	0 to 16
UV Index Accuracy	±5%
Wireless Transmission Range	Up to 1000 ft (300 m)
Temperature Range	-40°F to +150°F (-40°C to +65°C)
Humidity Range	0 to 100%
Humidity Accuracy	±3%
Rain Collector Resolution	0.01 in (0.2 mm)
Rain Measurement Accuracy	±4%
Wind Direction Range	0 to 360°
Power Supply	Solar powered with battery backup
