davoline SHAPE 060 BL - 7 Content of Package

7 CONTENT OF PACKAGE
10
9
11
Fig. 10
1 - Product
2 - Inner Flue
3 - Outer Flue
4 - Ø150/120mm Plastic Flue
Adapter (Option)
5 - Flue Connection Plate
6 - User Manual
7 - Installation Template
8 - Ø8mm Plastic Dowel
9 - Ø6mm Plastic Dowel
10 - 4.8x50 Wall Mount Screw
11 - 3.5x9.5 Flue Connection Screw
CONTENT OF PACKAGE
12.08.2020
User Manual
18
