n If there are protective sheets on
the flues, remove them (Fig. 14 /
1).
n By pulling the upper flue upwards
and screw to the flue connection
plate through the left and the right
sides ( Fig. 14 /2 ).
n Mount the lower flue to the body
through the left and the right sides.
(Fig. 14).
ASSEMBLY OF PRODUCT
Installation of the Sheet Metal Flue
12.08.2020
User Manual
22
