Setup: Saddle Position
Correct saddle adjustable is an important factor to get the
best performance and comfort from your E-Bike.
Up and down adjustment:
Your leg length determines the correct saddle height.
The saddle is at the correct height if you can just reach the
pedal with your heel, when the pedal is in it’s lowest position
and you are seated on the saddle. To check for correct sad-
dle height, perform the following:
1. Sit on the saddle, and place one heel on a pedal.
2. Rotate the crank until the pedal with your heel on it is
in the lowest position and the crank arm is parallel to
the seat tube. Your leg should be slightly bent and just
touching the center of the pedal. If this is not the case,
your saddle height needs to be adjusted.
Fig C - Dawes Arc Saddle
