9
Setup: Battery Checking
Fig A - Battery Lock (Located on on battery pack within the downtube)
Inserting, unlocking and removing the battery:
1. Release the lock lever from its clasp on the side of the
bike (as can be seen in step 4 on page 10)
2. Slot the battery into the downtube slot.
3. Insert the key and turn thekey clockwise, completing half
of a full turn to lock the battery pack into position.
4.To remove the battery, insert the key and turn it in an
anti-clockwise direction (unlocked), and use the handle on
the battery to pull it out from the downtube.
RoHS
