16
This bike has a pedal assisted drive system. In EU countries, it is known legally as “PAS” cycle or Pedal Assisted System.
The drive assisted system consists of a driving unit, a battery, a controller, and various electronic components (harness
wires, sensors and switches). It is important to know that when the assist system is turned on, the driving unit engages
to provide power only while you are pedaling. The amount of power provided by the drive unit depends on your pedal-
ing force and the assistance model/level you set with handlebar control unit at any time, if you stop pedaling, the drive
assistant will disengage. Upon all models/levels, the driving assisted system power reduces progressively and cuts o as
the bike reaches a speed of 25km/h,(15.5mph), or sooner if you stop pedaling. The drive assist re-engages when speed
drops below 25km/h, (15.5mph) as long as the pedals are turning.
• The E-Bike is equipped with multi-function display (see
photo at left.), Which shows the PAS level (5 levels),
‘Trip’ distance, total trip distance (ODO), battery level and
speed.
• To turn the E-Bike ON, hold the power button for
• 3 seconds
• Pressing the ‘-’ button will decrease the level of PAS, at
+1 you can pedal the bike normally with no pedal assist.
The drive system is not activated. holding down the (-)
button activates ‘Walking mode’, and allows the E-Bike to
travel at 6km/h, without pedaling.
• Pressing the ‘+’ button will increase the level of PAS, at
+6 the bike will have the maximum pedal assist. Range
dereases at higher pedal assist levels. Holding the +
button activates the screen’s backlight.
Fig J - PAS unit
Speed
PAS Level
Battery
charge
level
Trip
distance
