Dawlance DW 297 GSS User Manual

COUNTERTOP INSTALLATION
INSTALLATION
7.5cm
30cm
OPEN
1. Select a level surface that provides
enough open space for the intake
and/or outlet vents.
(c) Blocking the intake and/or outlet
openings can damage the oven.
(d) Place the oven as far away from
radios and TV as possible.
Operation of microwave oven may
cause interference to your radio or
TV reception.
2. Plug your oven into a standard
household outlet. Be sure the
voltage and the frequency is the
same as the voltage and the
frequency on the rating label.
The rear surface of appliance should
be placed against a wall.
A minimum clearance of 3.0 inches
(7.5 cm) is required between the oven
and any adjacent walls. One side must
be open.
(a) Leave a minimum clearance of 12
inches (30 cm) above the oven.
(b) Do not remove the legs from the
bottom of the oven.
WARNING: Do not install oven over a
range cooktop or other heat-producing
appliance. If installed near or over a heat
source, the oven could be damaged and
the warranty would be void.
The accessible surface
may be hot during
operation.
Remove all packing material and
accessories. Examine the oven for
any damage such as dents or
broken door. Do not install if oven
is damaged.
This microwave oven uses modern electronic control to adjust cooking parameters
to meet your needs better for cooking.
Cabinet: Remove any protective lm found
on the microwave oven cabinet surface.
Do not remove the light brown Mica cover
that is attached to the oven cavity to
protect the magnetron.
10 11
OPERATION
1. Clock Setting
When the microwave oven is electried,the oven will display "0:00", buzzer will ring once.
1) Press "CLOCK/PRE-SET" , the hour gure ash;
2) Press " " or " " to adjust the hour gures,the input time should be within 0--23.
3) Press "CLOCK/PRE-SET", the minute gures will ash.
4) Turn " " or " " to adjust the minute gures, the input time should be within 0--59.
5) Press "CLOCK/PRE-SET" to nish clock setting. ":" will ash, the " "indicator will go
out.The clock setting has been nished.
Note:
1) If the clock is not set, it would not function when powered.
2) During the process of clock setting, if you press " STOP/CLEAR ", the oven
will go back to the previous status automatically.
1. Clock Setting
When the microwave oven is electried,the oven will display "0:00", buzzer will ring once.
1) Press "CLOCK/PRE-SET" , the hour gure ash;
2) Press " " or " " to adjust the hour gures,the input time should be within 0--23.
3) Press "CLOCK/PRE-SET", the minute gures will ash.
4) Turn " " or " " to adjust the minute gures, the input time should be within 0--59.
5) Press "CLOCK/PRE-SET" to nish clock setting. ":" will ash, the " "indicator will go
out.The clock setting has been nished.
Note:
1) If the clock is not set, it would not function when powered.
2) During the process of clock setting, if you press " STOP/CLEAR ", the oven
will go back to the previous status automatically.
2. Microwave Cooking
1) Press the "Microwave/Grill/Combi." key once, and "P100" will display.
2) Press "Microwave/Grill/Combi." for times or press " "and " " to select the
microwave power from100% to 10%. "P100", "P80", "P50", "P30", "P10" will display
in order.
3) Press "START/+30SEC./CONFIRM" to conrm.
4) Press " " or " "to adjust the cooking time.
(The time setting should be 0:05- 95:00.)
5) Press " START/+30SEC./CONFIRM " to start cooking.
NOTE: the step quantities for the adjustment time of the coding switch are as follow:
2. Microwave Cooking
1) Press the "Microwave/Grill/Combi." key once, and "P100" will display.
2) Press "Microwave/Grill/Combi." for times or press " "and " " to select the
microwave power from100% to 10%. "P100", "P80", "P50", "P30", "P10" will display
in order.
3) Press "START/+30SEC./CONFIRM" to conrm.
4) Press " " or " "to adjust the cooking time.
(The time setting should be 0:05- 95:00.)
5) Press " START/+30SEC./CONFIRM " to start cooking.
NOTE: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
Microwave Power Chart
Microwave Power 80% 50% 30% 10%100%
Display
