1074 User Manual
11
Specifications
Input
Connectors: XLR (Pin 2 and tip hot)
Type: Electronically balanced/unbalanced, RF filtered
Impedance: Balanced > 50 kOhm, unbalanced >25 kOhm
Max Input Level: > +22 dBu balanced or unbalanced
CMRR: 40dB: Typically >55 dB at 1 kHz
Key Input: Electronically balanced/unbalanced, RF filtered Balanced 50 kOhm, unbal-
anced >25 kOhm
Output
Connectors: XLR (Pin 2 hot)
Type: Servo-balanced/unbalanced, RF filtered
Impedance: Balanced 60 Ohm, unbalanced 30 Ohm
Max Output Level: > +22 dBm balanced, > +20 dBm unbalanced
System Performance
Bandwidth: 20 Hz to 20 kHz, +0/-0.5 dB
Frequency Response: 0.35 Hz to 200 kHz, +0/-3 dB
Noise: < -96 dBu, unweighted, 22 kHz measurement bandwidth
Dynamic Range: > 115 dB, unweighted
THD+Noise: 0.008% typical at +4 dBu, 1 kHz unity gain
0.08% typical at +20 dBu, 1 kHz, unity gain
< 0.1% any amount of compression up to 40 dB, 1 kHz
Interchannel Crosstalk: < -80 dB 20 Hz to 20 kHz
Stereo Coupling: True RMS Power Summing
Power Supply
Operating Voltage: Factory selected: 100-120 VAC 50-60 Hz or 200-240 VAC 50/60 Hz
Power Consumption: 30 Watts
Fuse: 100-120 VAC: T 300 mA L 250V
200-240 VAC: T 160 mA L 250V
Mains Connection: IEC receptacle
Physical
Dimensions: 1.75”Hx19”Wx9”D (4.4cmx48.3cmx20.1cm)
Weight: 6.9 lbs.
Shipping Weight: 9.3 lbs.
Options
Output Transformer
Per Channel: Jensen® JT-123-dbx or BCI™ RE-123-dbx
Note: Specifications subject to change.
