SPECIFICATIONS
Input (1/4Ó TRS Phone and XLR) Floating Balanced; XLR: Pin 2 Hot, Phone: Tip Hot
Impedance 100k½ balanced, 50k½ unbalanced
Maximum Level +24dBu, Balanced or Unbalanced
CMRR >45dB (any frequency)
Detector Input (1/4Ó TRS Phone) Floating Balanced
Impedance 400k½ balanced, 200k½ unbalanced
Maximum Level +28dBu, Balanced or Unbalanced
Output (XLR) Floating Balanced; Pin 2 Hot
Impedance 30½
Maximum Level (Balanced) + 24dBm; <0.3% THD
Maximum Level (Unbalanced) +20dBm; <0.3% THD
Noise <-90dBu, Unweighted (20Hz - 20kHz)
Frequency Response 20Hz - 20kHz, + 0, -0.5dB; +0, -3dB 0.5Hz and 90kHz
THD+N <0.2%, Typical, Any Amount of Compression up to 40dB @ 1kHz
Output ( 1/4Ó TRS Phone)
Balancing Unbalanced
Impedance 20½
Maximum Level +24dBm
Dynamic Range >113dB
Gain Adjustment Range Variable from -20dB to +20dB
Threshold Range -40dBu to +20dBu
Threshold Characteristic Selectable OverEasy¨ or Hard Knee
Compression Ratio Variable 1:1 to °:1 thru to -1:1; >60dB Maximum Compression
Attack Time Program-Dependent; Typically 15ms for 10dB, 5ms for 20dB, 3ms
for 30dB
Release Time Program-Dependent; Typically 8ms for 1dB, 80ms for 10dB,
400ms for 50dB; 125dB/Sec Rate
Stereo Coupling True Power Summing; 1/4Ó TRS Phone Jack; 160A only
Power Cord IEC-Type Connector
Operating Voltage 100-120VAC or 220-240VAC
50/60Hz or 120V 60Hz
Operating Temperature 0¡C to 35¡C (32¡F to 95¡F)
Dimensions (H x W x D) 1.75Ó x 19Ó x 6.5Ó (4.45cm x 48.2cm x 16.51cm)
Rack Space 1 Rack Unit (1U High)
Weight Net Weight: 4.42 lbs (2.00 kg)
Shipping Weight: 6.62 lbs (2.99 kg)
Notes: Noise and frequency response specifications are at unity gain.
0dBV=1.0Vrms; 0dBu=0.775Vrms
Specifications are subject to change
14
