dbx 166XL - Specifications

SPECIFICATIONS
Inputs (1/4” TRS Phone and XLR) Floating Balanced; XLR: Pin 2 and TIP HI,
Entrées (Jack 6,35 tripolaire et XLR) Symétriques flottantes; signal (+) = broche 2 (XLR) et pointe (Jack)
Eingänge (1/4î TRS-Telefon und XLR) differential ausgeglichen; XLR: Stift 2 und TIP HI
Entradas (tripolar telefónico de 0,25 de pulgada y XRL) Simétricas flotantes; señal (+) = clavija 2 (XLR) TIP HI
Impedance >50k" balanced, >25k" unbalanced
Maximum Level +24dBu, Balanced or Unbalanced
CMRR >40dB at 1kHz, typically >55dB
Sidechain Insert (1/4” TRS Phone)
Circuit d'insertion Sidechain (Jack 6,35 tripolaire)
Sidechain-Einsatz (1/4î TRS-Telefon)
Sidechain (circuito de inserción) (tripolar de 0,5 de pulgada) Normalled: Ring = Output (send); Tip = Input (return)
Impedance Tip = >10k" (Input)
Ring = 2k" (Output)
Maximum Level +24dBu
Outputs (1/4” TRS Phone and XLR) Floating Balanced; XLR: Pin 2 and TIP HI
Sorties (Jack 6,35 tripolaire et XLR) Symétriques flottantes; signal (+) = broche 2 (XLR) et pointe (Jack)
Ausgänge (1/4î TRS-Telefon und XLR) differential ausgeglichen; XLR: Stift 2 und TIP HI
Salidas (tripolar telefónico de 0,25 de pulgada y XRL) Simétricas flotantes; señal (+) = clavija 2 (XLR)
Impedance 120" balanced, 60" unbalanced
Maximum Level +21dBu,>+20 dBm into 600", balanced or unbalanced
Frequency Response 20Hz - 20kHz; +0, -0.5dB,Typical 3dB points are 0.35Hz
and 110kHz, unity gain
Noise <-90dBu, 22Hz to 22kHz, no weighting, unity gain
THD+ N Typically <0.04%; Any Amount of Compression Up to
40dB@1kHz
SMPTE IMD Typically <0.08% @ +10dBu (15dB Gain reduction)
Compressor
Circuit de compression
Dynamikregelung
Circuito de compresión
Threshold Range -40dBu to +20dBu
Threshold Characteristic Selectable OverEasy or Hard Knee
Compression Ratio Variable; 1:1 to Infinity:1; 60dB Maximum Compression
Attack Time Variable program-dependent; 3ms to 340ms for 15dB gain reduction
Release Rate Variable program-dependent; 200dB/Sec to 3dB/Sec
Expander/Gate
Circuit expanseur/porte
Expander/Torschaltung
Circuito expansor/compuerta
Threshold Range OFF to +15dBu
Expansion Ratio 10:1
Maximum Depth >60dB
Attack Time <500µs (from Maximum Depth)
Release Time Adjustable, 30ms to 3sec (to 30dB attenuation)
PeakStop® Limiter
Limiteur PeakStop®
PeakStop®-Begrenzer
Limitador de crestas PeakStop*
Threshold Range 0dBu to +20dBu
Gain Adjustment Range
Gamme de réglage du gain
Dynamikregelung-Einstellbereich
Margen de ajuste de ganancia Variable; -20dB to +20dB
Interchannel Crosstalk
Diaphonie
Zwischenkanal-Kreuzkopplung
Intercomunicación de canales <-80dB, 20Hz to 20kHz
54
®
PROFESSIONAL PRODUCTS
dbx 166XL COMPRESSOR / GATE
