19
223s, 223xs,
234s, 234xs
14
Section 7 - Technical Specifications
CROSSOVER FREQUENCIES:
234s/234xs: Stereo Mode:
Low/High: 45 Hz to 960 Hz or 450 Hz to 9.6 kHz (x10 setting)
Low/Mid: 45 Hz to 960 Hz or 450 Hz to 9.6 kHz (x10 setting)
Mid/High: 450 Hz to 9.6 kHz
234s/234xs: Mono Mode:
Low/Low-Mid: 45 Hz to 960 Hz or 450 Hz to 9.6 kHz (x10 setting)
Low-Mid/High-Mid: 450 Hz to 9.6 kHz
High-Mid/High: 450 Hz to 9.6 kHz
223s/223xs: Stereo Mode:
Low/High: 45 Hz to 960 Hz or 450 Hz to 9.6 kHz (x10 setting)
223s/223xs: Mono Mode:
Low/Mid: 45 Hz to 960 Hz or 450 Hz to 9.6 kHz (x10 setting)
Mid/High: 45 Hz to 960 Hz or 450 Hz to 9.6 kHz (x10 setting)
Filter Type: Linkwitz-Riley, 24 dB/octave, state-variable
FUNCTION SWITCHES:
Front Panel:
Low Cut: Activates 40 Hz Butterworth, 12 dB/octave high-pass
filter, one switch per channel.
Phase Invert: Inverts the phase at the output, one switch per output.
Rear Panel:
x10: Multiplies crossover frequency range by 10, one switch per channel.
Mode: Selects stereo/mono and 2/3/4-way operation.
LF Sum: Selects normal (stereo) or mono-summed low frequency operation.
INDICATORS:
Stereo Operation: Green LED
Mono Operation: Yellow LED
Low Cut: Red LED per channel
x10: Green LED per channel
Phase Invert: Red LED per output (3 per channel)
POWER SUPPLY:
Operating Voltage: 100 VAC 50/60 Hz, 120 VAC 60 Hz
230 VAC 50/60 Hz
Power Consumption: 15 Watts
Mains Connection: IEC 320 receptacle
PHYSICAL:
Dimensions: 1.75” H X 19” W X 6.9” D (4.4cm x 48.3cm x 17.5cm)
Weight: 234: 4.0 lbs. (1.8 kg) 223s: 3.7 lbs. (1.7 kg)
Shipping Weight: 234: 5.8 lbs. (2.6 kg) 223s: 5.4 lbs. (2.5 kg)
Specifications are subject to change.
