dbx 576 - Technical Specifications: Power and Physical; Performance Metrics (cont.); Power Supply and Physical Data

Specifications (cont.)
THD + Noise: 0.04% typical at 0 dBu out, 1kHz, 33 dB gain
(Drive control at minimum, Level control at maximum)
3.5% typical at +21 dBu out, 1kHz, 35 dB gain
(tube saturation with Drive and Level controls at 50%)
Deviation From Linear Phase: < 20 degrees, 20 Hz to 20 kHz.
Interchannel Crosstalk: Typically -98 dB, 20 Hz to 20 kHz.
POWER SUPPLY:
Operating Voltage: Switchable between 100, 120, 230, and
240VAC, 50/60 Hz
Power Consumption: 30 Watts max.
Fuse: 100/120V: 500mA 250V Slow Blow 5mm X 20mm
230/240V: T250 mA 250V 5mm X 20mm
Mains Connection: IEC 320 Receptacle
PHYSICAL:
Dimensions: 3.5ÓH X 19ÓW X 8ÓD
Weight: 12 lbs (5.5 kg)
Shipping Weight: 13 lbs (5.9 kg)
Note: 0 dBu = 0.775V RMS. Specifications subject to change without notice.
