Installer F inal Checklis t
16
GENERAL
Placement of Unit.
Specified clearance maintained to cabinet
surfaces.
Unit Level- front to back, side to side.
All packaging material and tie straps removed.
ELECTRICAL:
Receptacle with 15 ampere current
protection is provided for service cord
connection.
Adequate ground connection.
GAS SUPPLY:
Connection: 1/2 NPT with a minimum 5/8”
diameter flex line
The pressure regulator which is connected to
the manifold is set for 4.0”-for Natural Gas
Manual gas shut off valve installed in an
accessible location.
Unit tested and free of gas leaks
OPERATION:
All internal packing materials are removed, i.e.
below grates, around knobs, etc.
Bezels centered on burner knobs and knobs
turn freely.
Each burner lights satisfactorily, both
individually and with other burners operating.
Flame adjustment for 3/8" soft blue cone
made on ports of each top burner.
Low flame operation verified.
All burner caps, burner rings and burner
bases correctly seated in position, level, and
do not rock or slide.
Burner grates correctly positioned, level, and
do not rock.
