CLEARANCES
7
0
0
INSTALLATION (MINIMUM CLEARANCES TO NON-COMBUSTIBLE MATERIAL).
FLOOR
96"
Four Bolts
Per Bracket
SIDE VIEW
Surface
Non Combustible
1/2" Conduit
(installer supplied)
Gas Shut-off
Valve
(installer supplied)
Gas Pipe
(installer supplied)
Utilize 2
bolts (min)
per bracket.
Drip Leg
min.
Make sure heater is level
(see warning on page 9)
0
0
& 30
0
INSTALLATION (MINIMUM CLEARANCES TO COMBUSTIBLE MATERIAL).
48"
18"
min
min
18"
Front View
Wall
(Combustible
Surface)
Wall
(Combustible
Surface)
Heater Mounting
Body Assy.
